P-840 Preloaded Piezo Actuators

Compact Actuators for High Loads and Forces

P-840 Preloaded Piezo Actuators
Product Description Specifications Downloads Quote / Order
  • Outstanding lifetime due to PICMA® piezo actuators
  • Travel range to 90 µm
  • Compact housing
  • Push force capacity to 1000 N
  • Pull force capacity to 50 N
  • Microsecond response
  • Subnanometer resolution
  • Versions with ball tip, vacuum versions

Fields of application

  • Static and dynamic precision positioning
  • Fiber positioning
  • Laser tuning
  • Nanotechnology

Outstanding lifetime thanks to PICMA® piezo actuators

The patented PICMA® piezo actuators are all-ceramic insulated. This protects them against humidity and failure resulting from an increase in leakage current. PICMA® actuators offer an up to ten times longer lifetime than conventional polymer-insulated actuators. 100 billion cycles without a single failure are proven.

Suitable for sophisticated vacuum applications

Piezo actuators do not require lubrication and do not cause abrasion. The all-ceramic isolated PICMA® actuators also do not require polymer isolation and are therefore ideal for vacuum applications.

Specifications

Datasheet P-840

Version / Date
2018-05-22
Version / Date
2018-05-22
Version / Date
2018-05-22
Document language
pdf - 738 KB
pdf - 679 KB
pdf - 658 KB

Downloads

Datasheet

Datasheet P-840

Version / Date
2018-05-22
Version / Date
2018-05-22
Version / Date
2018-05-22
Document language
pdf - 738 KB
pdf - 679 KB
pdf - 658 KB

Documentation

User Manual P840M0001

P-840 Preloaded piezo actuators
Version / Date
2018-11-13
Version / Date
2018-11-13
Document language
pdf - 2 MB
pdf - 2 MB

User Manual P840M0002

P-840.xxV Preloaded piezo actuators (vacuum versions)
Version / Date
2018-11-13
Version / Date
2018-11-13
Document language
pdf - 3 MB
pdf - 3 MB

3-D Models

P-840 P-841 3-D model

Quote / Order

Ask for a free quote on quantities required, prices, and lead times or describe your desired modification. All products available online can be ordered directly.

Actuators without sensor

Actuators without sensor, vacuum compatible

Actuators without sensor, with tip

Actuators without sensor, with tip, vacuum compatible
